Stripping Machines

RotoStrip-100

ROTARY STRIPPING MACHINE ( CABLE OUTER DIA 4 MM TO 20.0 MM,STRIPPING LENGTH 5 MM TO 100.0 MM )

ROTARY STRIPPING MACHINE ( CABLE OUTER DIA 4 MM TO 20.0 MM,STRIPPING LENGTH 5 MM TO 100.0 MM )

The RotoStrip-100 is a semi-automatic rotary stripping machine designed for efficient and precise stripping of a wide range of cables, including PVC wires, solid core, single stranded, rubber wires, multi-core cables, computer core wires, and battery cables. It features an HMI touchscreen interface for intuitive operation and supports high-precision stripping up to 50 sq.mm wire size.

HMI (Touchscreen) Control: User-friendly interface for easy programming and operation.
Supports Multiple Cable Types: PVC, solid core, single stranded, rubber wires, multi-core cables.
High Precision Rotary Stripping: Accurate depth and speed control for clean stripping.
Digital Input Settings: Stripping depth, speed, and rotation time can be programmed easily.
Pneumatic Wire Clamping: Ensures firm grip during operation for consistent quality.

An Affordable Excellence Machine

This standard crimp machine is designed for crimping terminals using quick change applicators and for using both at the same time, in one single operation.

Highlights Technical Specifications Processing Capabilities Downloads Related Products

Highlights

Touchscreen Control

Easy programming.

Wide Compatibility

Supports many cable types.

Precise Stripping

Clean rotary cutting.

Firm Clamping

Stable pneumatic grip.

Technical Specifications

Specifications	Details
Model	RotoStrip-100
Operating Interface	HMI (Touch Screen)
Supported Wire Types	PVC, Solid Core, Single Stranded & Rubber Wires, Multicore
Minimum Cable Outer Diameter	4.0 mm
Maximum Cable Outer Diameter	20 mm
Cable Size	4 sq.mm to 50 sq.mm
Maximum Stripping Length	100.0 mm
Length Accuracy	±0.2 mm (L × 0.04%) depends on materials
Noise Level	< 70 dB
Air Supply	> 6.0 bar (dried & filtered air)
Power Supply	230 to 240V (50/60 Hz)
Function Mode	Foot Pedal / Push Button
Power Consumption	600 Watts
Cylinder Stroke	100 mm
Dimensions (L × W × H)	1000 × 330 × 430 mm
Net Weight	90 kg
Output Range (approx)	1200 – 1500 pcs/hour (depending on operator skill)
Uninyvin Cable Size	12 to 0

Model

Model 1 RotoStrip-100

Operating Interface

Model 1 HMI (Touch Screen)

Supported Wire Types

Model 1 PVC, Solid Core, Single Stranded & Rubber Wires, Multicore

Minimum Cable Outer Diameter

Model 1 4.0 mm

Maximum Cable Outer Diameter

Model 1 20 mm

Cable Size

Model 1 4 sq.mm to 50 sq.mm

Maximum Stripping Length

Model 1 100.0 mm

Length Accuracy

Model 1 ±0.2 mm (L × 0.04%) depends on materials

Noise Level

Model 1 < 70 dB

Air Supply

Model 1 > 6.0 bar (dried & filtered air)

Power Supply

Model 1 230 to 240V (50/60 Hz)

Function Mode

Model 1 Foot Pedal / Push Button

Power Consumption

Model 1 600 Watts

Cylinder Stroke

Model 1 100 mm

Dimensions (L × W × H)

Model 1 1000 × 330 × 430 mm

Net Weight

Model 1 90 kg

Output Range (approx)

Model 1 1200 – 1500 pcs/hour (depending on operator skill)

Uninyvin Cable Size

Model 1 12 to 0

Processing Capabilities

Cutting to length

Full stripping

Ferrule crimping

Cutting pulled strands / Zero cut

Partial stripping

Wire end solidifying, splicing, welding

Get the full product details

You can explore features, Specifications and benefits in our brochure. Our brochure provides insights into cutting-edge automation solutions designed to boost efficiency, precision, and performance.
