Stripping Machines

BraidStrip-7008 Series

BRAIDED WIRE STRIPPING, CUTTING & FLIPPING MACHINE

BRAIDED WIRE STRIPPING, CUTTING & FLIPPING MACHINE

The BraidStrip-7008 Series is a high-precision, fully automated solution designed specifically for braided wires used in new-energy, automotive, and high-voltage cable applications. Equipped with an advanced X-Y axis translation mechanism and a single-clamp operating structure, the system ensures exceptional dimensional accuracy and stable processing performance.With modular functional combinations—including braid cutting, flipping, brushing, CCD inspection, and defective product.

Designed for New-Energy Braided Wires Precision processing for multi-layer shielded and high-voltage cables.
High-Accuracy X-Y Axis Translation Platform Ensures stable stripping, cutting, and braid handling with excellent repeaability.
Single-Clamp Process Control Improves dimensional consistency and reduces mechanical errors.
Motor-Controlled Position Adjustment Parameter-driven setup offers quick and convenient product changeovers.

An Affordable Excellence Machine

This standard crimp machine is designed for crimping terminals using quick change applicators and for using both at the same time, in one single operation.

Highlights Technical Specifications Processing Capabilities Downloads Related Products

Highlights

New-Energy Cable Ready

Ideal for braided, multi-layer, and high-voltage cables.

High Precision Motion Control

X-Y axis translation ensures repeatable accuracy.

Single-Clamp Stability

Improves stripping consistency and quality.

Quick Changeovers

Motor-controlled positioning with fast setup.

Technical Specifications

Specifications	Details 1	Details 2	Details 3	Details 4
Model	BraidStrip-7008A	BraidStrip-7008-FB01	BraidStrip-7008J	BraidStrip-7008SF
Functions	Stripping / Braid Cutting / Braid Flipping / Inner Wire Stripping	Stripping / Braid Cutting / Braid Flipping / Inner Wire Stripping	Stripping / Braid Cutting / Braid Flipping / Inner Wire Stripping / CCD Inspection / Defective Product Cutting	Stripping / Braid Cutting / Braid Flipping / Inner Wire Stripping / Braid Brushing
Processing Range	3–95 mm²	3–120 mm²	3–120 mm²	3–120 mm²
Max. Stripping Length	≤130 mm	≤280 mm	≤200 mm	≤200 mm
Shield Retention Length	5–30 mm	5–30 mm	5–30 mm	5–30 mm
Power Supply	Single-phase AC 220V, 50/60 Hz	Single-phase AC 220V, 50/60 Hz	Single-phase AC 220V, 50/60 Hz	Single-phase AC 220V, 50/60 Hz
Power Rating	1.5 kW	2.5 kW	2.8 kW	2.8 kW
Dimensions (L × W × H)	1200 × 800 × 1200 mm	1600 × 870 × 1254 mm	1600 × 1200 × 1450 mm	1500 × 1100 × 1450 mm
Air Supply	0.5 – 0.7 MPa	0.5 – 0.7 MPa	0.5 – 0.7 MPa	0.5 – 0.7 MPa

Model

Model 1 BraidStrip-7008A

Model 2 BraidStrip-7008-FB01

Model 3 BraidStrip-7008J

Model 4 BraidStrip-7008SF

Functions

Model 1 Stripping / Braid Cutting / Braid Flipping / Inner Wire Stripping

Model 2 Stripping / Braid Cutting / Braid Flipping / Inner Wire Stripping

Model 3 Stripping / Braid Cutting / Braid Flipping / Inner Wire Stripping / CCD Inspection / Defective Product Cutting

Model 4 Stripping / Braid Cutting / Braid Flipping / Inner Wire Stripping / Braid Brushing

Processing Range

Model 1 3–95 mm²

Model 2 3–120 mm²

Model 3 3–120 mm²

Model 4 3–120 mm²

Max. Stripping Length

Model 1 ≤130 mm

Model 2 ≤280 mm

Model 3 ≤200 mm

Model 4 ≤200 mm

Shield Retention Length

Model 1 5–30 mm

Model 2 5–30 mm

Model 3 5–30 mm

Model 4 5–30 mm

Power Supply

Model 1 Single-phase AC 220V, 50/60 Hz

Model 2 Single-phase AC 220V, 50/60 Hz

Model 3 Single-phase AC 220V, 50/60 Hz

Model 4 Single-phase AC 220V, 50/60 Hz

Power Rating

Model 1 1.5 kW

Model 2 2.5 kW

Model 3 2.8 kW

Model 4 2.8 kW

Dimensions (L × W × H)

Model 1 1200 × 800 × 1200 mm

Model 2 1600 × 870 × 1254 mm

Model 3 1600 × 1200 × 1450 mm

Model 4 1500 × 1100 × 1450 mm

Air Supply

Model 1 0.5 – 0.7 MPa

Model 2 0.5 – 0.7 MPa

Model 3 0.5 – 0.7 MPa

Model 4 0.5 – 0.7 MPa

Processing Capabilities

Cutting to length

Full stripping

Ferrule crimping

Cutting pulled strands / Zero cut

Partial stripping

Wire end solidifying, splicing, welding
