Precise & Efficient
Foot-pedal control with adjustable stripping and cutting.
Stripping Machines
AirStrip-400 Plus
PNEUMATIC THERMAL WIRE STRIPPING MACHINE FOR 0.25 TO 4.0 SQ.MM
Pneumatic Wire Stripper – Compact and portable automatic machine, ideal for stripping multi-conductor, PVC, solid core, single-stranded, computer, telephone, and flat wires.
Foot-pedal controlled, precise and efficient with adjustable stripping and cutting.
Durable.
Lightweight
Ideal for single- and multi-core cables.
An Affordable Excellence Machine
This standard crimp machine is designed for crimping terminals using quick change applicators and for using both at the same time, in one single operation.
Highlights
Durable Build
Designed for long operational life.
Lightweight
Easy to move and position.
Versatile Use
Ideal for single- and multi-core cables.
Technical Specifications
Model
Model 1 AirStrip-400 Plus
Wire Type
Model 1 PVC, Solid Core, Single Stranded & Rubber Wires, Braided Cables
Minimum Cable Size
Model 1 0.25 sq.mm
Maximum Cable Size
Model 1 4.0 sq.mm
Maximum Stripping Length
Model 1 20.0 mm
Length Accuracy
Model 1 ±0.2 mm (L × 0.04%) depending on materials
Noise Level
Model 1 < 70 dB
Air Supply
Model 1 > 6.0 bar (dried & filtered air)
Power Supply
Model 1 230 to 240V (50/60 Hz)
Cylinder Stroke
Model 1 20 mm
Dimensions (L × W × H)
Model 1 260 × 150 × 270 mm
Net Weight
Model 1 9.5 kgs
Output Range (approx)
Model 1 1500 – 2000 pcs/hour (depends on operator skill)
Function Mode
Model 1 Foot Pedal
Blade Temperature
Model 1 Up to 200°C
Processing Capabilities
Cutting to length
Full stripping
Ferrule crimping
Cutting pulled strands / Zero cut
Partial stripping
Wire end solidifying, splicing, welding
Get the full product details
You can explore features, Specifications and benefits in our brochure. Our brochure provides insights into cutting-edge automation solutions designed to boost efficiency, precision, and performance.
