High Precision
0.1 mm stripping tolerance.
Stripping Machines
AirStrip-250
PNEUMATIC WIRE STRIPPING MACHINE FOR 0.25 TO 2.5 SQ.MM
Small Wire Stripping Machine – High-speed machine for very small diameter wires. Suitable for discrete, solid, single-stranded, single-core, rubber, PVC, PUR, and PTFE wires.
High-Precision Wire Stripper – 0.01 mm tolerance.
Compact design.
Universal blades.
Ideal for multi-core and flat cables.
An Affordable Excellence Machine
This standard crimp machine is designed for crimping terminals using quick change applicators and for using both at the same time, in one single operation.
Highlights
Compact Design
Small and efficient workspace fit.
Universal Blades
Compatible with multiple wire types.
Versatile Use
Suitable for single-core and flat cables.
Technical Specifications
Model
Model 1 AirStrip-250
Type
Model 1 Pneumatic
Wire Size Range
Model 1 0.25–2.5 sq.mm
Max. Outer Diameter
Model 1 3.2 mm
Stripping Length
Model 1 6–16 mm
Partial Strip
Model 1 Yes
Pull-off Length
Model 1 6–20 mm
Power Supply
Model 1 AC 220V, 50/60 Hz
Weight
Model 1 5 kg
Dimensions (L × W × H)
Model 1 370 × 90 × 180 mm
Processing Capabilities
Cutting to length
Full stripping
Ferrule crimping
Cutting pulled strands / Zero cut
Partial stripping
Wire end solidifying, splicing, welding
Get the full product details
You can explore features, Specifications and benefits in our brochure. Our brochure provides insights into cutting-edge automation solutions designed to boost efficiency, precision, and performance.
