Heat Shrink Machines
HeatStream-20
HEAT SHRINK TUBE RECIPROCATING PRECISION SPOT HEATER FOR SHRINK TUBES PROCESSING MACHINE ( TUBE DIAMETER RANGE Ø1.0 MM TO Ø20.0 MM)
HeatStream-20 is a reciprocating linear movement heat shrink machine designed for larger diameter insulation tubes. The sliding heating chamber delivers uniform heat distribution along the tube length, ideal for automotive and industrial harness production where longer and thicker shrink sleeves are used.
Reciprocating heating mode improves uniform shrink quality
Supports tube length up to 90mm with max Ø20mm diameter
Fast thermal response with max 600°C output
AC 220V standard power supply, factory compatible
An Affordable Excellence Machine
This standard crimp machine is designed for crimping terminals using quick change applicators and for using both at the same time, in one single operation.
Highlights
Technical Specifications
Model
Model 1 HeatStream-20
Thermal Temperature
Model 1 Max. 600°C
Input Voltage
Model 1 AC 220V
Tube Length Capacity
Model 1 Max. 90 mm
Heating Panel Size
Model 1 Ø40 mm × 102 mm
Maximum Tube Outer Diameter
Model 1 Up to 20 mm
Heating Method
Model 1 Reciprocating sliding heating for uniform shrink
Application Field
Model 1 Heat shrinking of long insulation sleeves, thick-wall tubes, and protective wire tubing
Processing Capabilities
Cutting to length
Full stripping
Ferrule crimping
Cutting pulled strands / Zero cut
Partial stripping
Wire end solidifying, splicing, welding
