Point-Type Precision
Advanced heat shrinking technology for accuracy.
Heat Shrink Machines
HeatStream-15H
HEAT SHRINK TUBE RECIPROCATING PRECISION SPOT HEATER FOR SHRINK TUBES PROCESSING MACHINE ( TUBE DIAMETER RANGE Ø1.0 MM TO Ø15.0 MM)
HeatStream-15H is a compact point-type localized heating unit designed for precision heat shrink applications on cable ends, spot heating for welding points and rivet press areas. It provides controlled, concentrated thermal profiles for high accuracy wire harness production processes.
Point-type precision heat shrinking technology
Supports maximum tube length 70mm and up to Ø15mm tube size
Max 600°C high thermal output for ultra-fast shrinking
Ideal for welding spot heating and rivet press point preparation
An Affordable Excellence Machine
This standard crimp machine is designed for crimping terminals using quick change applicators and for using both at the same time, in one single operation.
Highlights
Tube Support
Up to 70 mm length and Ø15 mm size.
High Thermal Output
Max 600°C for ultra-fast shrinking.
Versatile Application
Ideal for welding spot heating and rivet prep.
Technical Specifications
Model
Model 1 HeatStream-15H
Thermal Temperature
Model 1 Max. 600°C
Input Voltage
Model 1 AC 220V
Tube Length Capacity
Model 1 Max. 70 mm
Heating Panel Size
Model 1 Ø32 mm × 77 mm
Maximum Tube Outer Diameter
Model 1 Up to 15 mm
Operating Function
Model 1 Local heating for shrink tube / welding point / riveting press point
Application Field
Model 1 Wire end localized heat shrinking, terminal welding point heating, press-fit rivet point
Processing Capabilities
Cutting to length
Full stripping
Ferrule crimping
Cutting pulled strands / Zero cut
Partial stripping
Wire end solidifying, splicing, welding
Get the full product details
You can explore features, Specifications and benefits in our brochure. Our brochure provides insights into cutting-edge automation solutions designed to boost efficiency, precision, and performance.
