Crimp Force Monitor
ForceTron-2 C
DUAL-CHANNEL CRIMP FORCE MONITORING SYSTEM
Dual-Channel Crimp Force Monitor ensures real-time crimping quality by detecting faulty crimps early. Its dual-channel design allows monitoring of two stations simultaneously for higher productivity.
Dual-Channel Monitoring: Monitors two crimping processes simultaneously
Integrated Barcode Scanner: For job and operator verification
Data Loading & Scan Reset: Quick setup and efficient workflow
Touchscreen Interface: Color LCD for easy operation
An Affordable Excellence Machine
This standard crimp machine is designed for crimping terminals using quick change applicators and for using both at the same time, in one single operation.
Highlights
Technical Specifications
Product Type
Model 1 Dual-Channel Crimp Force Monitor
Display
Model 1 Color LCD Touchscreen
Channels
Model 1 2 (Dual-channel monitoring)
Measuring Time
Model 1 400 ms per cycle
Power Supply
Model 1 AC 100–240 V, 50 Hz
Communication
Model 1 USB plug
Functions
Model 1 Barcode scanning, Data loading, Scan reset
Accuracy
Model 1 ±1%
Operating Temp
Model 1 0°C to 45°C
Sensor Type
Model 1 Frame/Base Plate/Ram sensor
Suitable
Model 1 2 Ton / 4 Ton / 6 Ton / 8 Ton / 10 Ton / 20 Ton / 30 Ton / 50 Ton
Processing Capabilities
Cutting to length
Full stripping
Ferrule crimping
Cutting pulled strands / Zero cut
Partial stripping
Wire end solidifying, splicing, welding
